Using DCD-SND.12 – Screw and Nut Driver Set

Three Handles, Three essential (-) type screwdriver tips, 3 essential (+) type screwdriver tips and 3 important Nut Drivers for use with model railways and similar hobbies.

Have you ever wondered why some modellers keep using the same tools, year in, year out, while others always seem to need to buy replacements?

This usually happens because with ALL tools,there is a “right or wrong” way to use them to make sure they last!

The Handles

They are made from tough alloys and have been anodised to prevent corrosion. They will rarely ever wear out, but basic care will keep them in perfect condition.

Wipe them down after use, especially if you are soldering or using them near strong chemicals.

Oil the rotating “Palm Pad” occasionally so that it rotates easily when you are removing and tightening screws.

The Tips

All of our Screwdriver and Nut Driver tips are hardened, but excessive force OR using the wrong size tip for the job you are doing can still cause wear or damage them.

Choose the correct size tip carefully: This is important because the screws and nuts in today’s models are NOT usually hardened. While the screwdriver tip MAY not be damaged if you do not match the screw and the driver tip you choose, the screw itself will very often be quite badly damaged by any significant mis-matching.

Pack contents:
1x 1.5mm slot
1x 2mm slot
1x 2.5mm slot
1x PH00
1x PH0
1x PH1
1x 2mm hex nut
1x 2.5mm hex nut
1x 3mm hex nut

Making the Choice

Nut Drivers should fit the Nut smoothly with NO slop. Any slop will almost certainly cause Driver or Nut damage.

Blade-type tips must NOT be too small and “sloppy” in the screw head. This will chew out the centre of the screw and the under-sized driver tip may also be damaged.

Cross-type tips must NOT be significantly smaller than the screw-head. This will damage the screw and may also allow too much leverage, damaging the too-small tip.

Cross-type tips must NOT be significantly larger than the screw-head recess. This will badly damage a screw-head quite quickly, making it impossible to remove it.
